Dome Cap Nut Stainless Steel
Product Specifications
- Material: Stainless Steel 304 / 316
- Type: Dome Cap Nut / Acorn Nut
- Standard: DIN 1587
- Size Range: M4 – M24 (custom sizes available)
- Thread Type: Metric
- Finish: Polished / Natural Stainless
Wedge Anchor (Copy)
Mechanical Wedge Anchor widely used for medium to heavy-duty through fixing with steel expansion clip.
Material
- Carbon steel with electro galvanised to 5 microns / Hot dipped galvanised
- Stainless steel A2-70 (SUS304), A4-70 (SUS316)
Wedge Anchor
Mechanical Wedge Anchor widely used for medium to heavy-duty through fixing with steel expansion clip.
Material
- Carbon steel with electro galvanised to 5 microns / Hot dipped galvanised
- Stainless steel A2-70 (SUS304), A4-70 (SUS316)
High Strength Tension Control Bolt (TC Bolt)
Standard :
BS EN 14399-10, JIS B 1186
Material :
Black, Plain, Zinc Plated And and other special coatings
Threaded Bolt
Standard:
DIN 975, ASTM A193
Material grade:
4.8, 8.8, B7, A2(304), A4(316)
Finishing :
Black, Galvanized, Hot Dipped Galvanized
Wafer Head M5.0-24x25MM
Screw Diameter: M5 / #10 gauge
Thread form: 24 threads per inch
Screw head drive: #2 Philips Bit
Drill capacity: Up to 3.5mm thickness (#2 point)
Material: Case Hardened Carbon Steel
Protective Coating: Ruspert Silver AS3566 Class 3
Hex Wafer Head M6.3-24x22MM
Screw Diameter: M6.3 / #14 gauge
Thread form: 14 threads per inch
Screw head drive: 3/8” (10mm) Hex Drive
Drill capacity: <2.5mm thickness (Reduced point)
Material: Case Hardened Carbon Steel
Protective Coating: Ruspert Silver AS3566 Class 3
Hex Wafer Head M5.5-24x65mm – Double Thread With Grey EPDM Washer
Screw Diameter: M5.5 / #12 gauge
Thread form: 24 threads per inch
Screw head drive: 5/16” (8mm) Hex Drive
Drill capacity: Up to 6mm thickness (#3 point)
Material: Case Hardened Carbon Steel
Protective Coating: Ruspert Silver AS3566 Class 3
